Creating Etherial Long Exposures With Breakthrough Photography’s X4 ND Filters


The  Peace Of The Creative…

Slowing down creates peace on multiple levels.

For you as the photographer and for those who view your work, this has never been more true!

Roanoke Marshes Light. Fuji GFX 50R for 20 seconds with a Breakthrough X4 6 stop ND and the X4 2 stop soft graduated ND

I am going to do a slightly different type of post this time.

We will discuss the art of Long Exposures a bit but we will focus more on the technical aspects of using ND filters to correct for different types of lighting as well as talk about good ND filter systems verses not so good, and why it is always best to invest your money in good filters!

Definition:  Long Exposure – To create an image in camera with the shutter open for longer than a few seconds in order to smooth out movement over time.  This can be softening the  flow of water over a waterfall, flattening of waves in lakes and oceans or tearing clouds moving across the sky.

Setup:  For camera setup you want a long shutter speed (for me usually from 20 seconds to 60 min), mid range aperture (f/16)  and the base ISO that your camera provides.  You do NOT want to switch on the L ISO in your camera. While it  forces the ISO lower it costs you in reduced dynamic range! You should also verify that your camera has Long Exposure Noise Reduction turned on.  This is a royal pain due to doubling of exposure time and forcing you to wait twice as long for a shot but it removes sensor generated noise as well as sensor hot spots.

Note:  I have added a video to the bottom.  It discusses everything and more that we are talking about in this post but it is quite long!

The top image was taken at the always inspiring Roanoke Marshes Lighthouse across the sound from Nags Head Island in NC. As one of my favorite locations for sunrises over the lighthouse it is also a most worthy location for daytime long exposures! These are usually very easy to create due to the small waves in the sound! This image was done on a Fuji GFX 50R medium format digital with a 32-64mm GF lens, 6 stops of ND (Breakthrough X4 magnetic) and a X4 2 stop soft graduated ND on the sky to balance the difference between the sky and water. The exposure was 20 seconds an hour after sunrise and in the rain.

But by what criteria did I choose the solid ND and the soft edge graduated ND?  This is where a little technical knowledge will really help you in creation of amazing long exposures.

First, there are a few points to consider when thinking about using ND filters:

  • ND filters are simply sunglasses that you put in front of your lens to limit the amount of light that reaches the camera.
  • There are 2 basic styles of ND, Full and Graduated.  Full covers and darkens light passing through the  entire lens, Graduated cover and darken only part of the light passing through the lens with the ability to rotate the edge angle of the start line and moving the line up or down in the scene.
  • In the full family there are several values and styles.Breakthrough Magnetic lens mount with the rotating dial on the back to rotate the filter
    • Screw on:  they simply screw onto the end of your lens
    • Magnetic:  these are a new (2018) system from Breakthrough Photography.  They require you to buy a special magnetic mount bracket for the filter threads on your lens.  The adapter has a rotating ring that allows the filters to be actually turned (for use with polarizers) and costs about $20. Currently, Breakthrough is re-designing both the magnetic filters and the magnetic lens adapters to allow for stacked magnetic filters.  This should be completed by summer 2019 and they will replace the older style magnetic filters and adapters. It is important to tell you that when you use the magnetic filter system alone or with the square system there is NO vignetting.
    • Breakthrough Square holder that attaches to the magnetic adapter
    • Square:  these use a square holder and in the case of the Breakthrough this holder will attach directly to the magnetic holder allowing use of and stacking of both systems at once. The square holder will hold 3 to 5 filters depending upon how you initially set it up. This is good for difficult lighting situations where you might need two different graduated filters at the same time.  This style  tends to suffer from light leaks around the edges of the square solid ND filters unless you carefully assure  that they are installed exactly right and only in the holder slot closest to the lens.
  • In the graduated family there are several types:Breakthrough Photography X4 soft Graduated 100mm filter system
    • Hard edge graduated:  where the dark area of the graduated filter is a sharp line.  This is for use on subjects which have a harsh division between the foreground and background . An example would be shooting on the ocean where the horizon is a sharp line between the horizon and the sky.  This is where you would choose a hard edge graduated ND.  These filters usually come in 1, 2 and 3 stop values where they start light and graduate to the dark.
    • Breakthrough reverse grad
    • Soft edge graduated: where the dark edge of the graduated filter starts very soft and  light and darkens as it moves up the filter.  This is for use in areas that you need to balance the foreground from the background but there is no clearly defined edge in the scene.  This is what I used in the image above to darken the sky so there was detail there and still enable the water foreground to be bright and almost a platinum look and feel.  These filters usually come in 1, 2 and 3 stop values where they start light and graduate to the dark.
    • REVERSE graduated:  this is a special graduated ND where it starts DARK and graduates up to lighter values.  If you desire to shoot sunrise/sunset this is a MUST have filter because as the sun approaches the horizon you get a very bright line of colors there that will either be blown out or if exposed correctly cause the rest of the image to be way too dark!  These filters usually come in 1, 2 and 3 stop values where they start dark and graduate to the light.
Breakthrough Photography Magnetic filter system.

So for the Roanoke Marshes Light above, I chose a Breakthrough magnetic X4 (newest technology) 6 stop solid nd to darken the entire image allowing for the 20 second exposure with the camera set to the lowest native ISO value (100),  an aperture of f/16 and a shutter speed of 20 seconds.  the initial results of this exposure was pleasing water in the foreground but the sky was also too light with little to no detail.  So I left the 6 stop magnetic filter on the lens and clipped on the 100mm square filter adapter onto the end of the magnetic adapter and installed a X4 soft edge 2 stop SOFT graduated ND filter.  While watching thru the viewfinder I adjusted the graduated ND up and down making sure that the soft edge came down to the horizon or a little above darkening the sky to allow for more detail there yet allowing the soft white water in the foreground!  It was as simple as that!  The entire process after the first shot took about 30 seconds to setup on the camera lens then shoot!



So let’s talk about sunrise/sunset images when the sun is close to the horizon.  We have all been out at sunrise, do you remember the very bright band of intense color that it right at the horizon as the sun approaches?   This is why the reverse grad ND filter was created, to keep the bright colors from destroying the overall exposure!  Here is an example image, amazingly at the same spot!

Roanoke Marshes Light, 3 seconds with the Breakthrough reverse grad placed on the horizon
Breakthrough X4 reverse grad.  See how you might place the dark area on the bright line at the horizon?

Do you see how bright the light is at the horizon?  The ONLY WAY I was able to capture this image was to use the reverse grad ND placing the dark section right on the bright band of light. Because the overall exposure was only 3 seconds no other ND filters were required.  Should I have desired a longer exposure to further soften the water’s surface I would have dropped in the 3 or 6 stop X4 magnetic filter into the adapter already on the camera!

Let’s take a short side trip here and discuss the actual filters.  By now you all have seen that I am a strong user and promoter of the Breakthrough Photography X4 line of magnetic and graduated filters.  There is a reason for that:

  • All dark solid ND filters suffer from some sort of light leaks around the slide in filter holder.  The magnetic mounted X4 Breakthrough filter line has solved this problem.
  • The X4 Breakthrough filters have ZERO COLOR CAST!  This is a really big deal.  I have been a big user of B+W and Lee filters over the years and still have them on hand.  Unfortunately, both of those both have strong color casts that force me deeper into post processing to attempt to correct these color casts.  I had always thought that this was simply the cost of doing long exposure!  Well NO MORE!   I am so pleased to report that those problems are not the case with Breakthrough, ALL BREAKTHROUGH filters!  Cost wise they all cost about the same when you get up into the same quality levels (B+W, Lee, SinghRay and Breakthrough).  So for me it was an easy choice, I have totally converted over to the Breakthrough X4 line of filters. I currently am using the magnetic and square system from them.
  • There is ZERO vignetting with the magnetic system on ANY of my lenses.  I currently and using 72mm, 77mm and 82mm lenses and mounting both the magnetic system and the 100mm system together!
  • Breakthrough filters come with a 25 year guarantee and their customer service is crazy good.  They are currently (Feb 2019) working on an updated magnetic system where the filters can be stacked in the holder!



So my advice is this.  Cameras come and go, it is your glass (lenses and filters) where your quality lays.  Invest in the best you can.  You will never go wrong with the Breakthrough system!  (gee I wish they would pay me…)

Ok, back to images.  After sunrise is done and before sunset is anywhere near we can still create AMAZING long exposures!  There only 2 problems that we must overcome!

  1. Slowing down the shutter speed to give the long exposure.  During normal daylight we will likely be using a 10 or 15 stop solid magnetic X4 ND as long as the sky and the foreground are near the same exposure value.
  2. Should the sky be brighter than the foreground we will also use a X4 soft edge graduated ND filter to balance the foreground and sky.
Pawleys Island Pier in dense fog. The foreground and sky are close to the same brightness so I only needed a 15 stop X4 magnetic filter

Here is an example of a scene with little difference between the sky and the foreground. The waves were HUGE this day so I used a X4 14 stop magnetic filter so smooth them down (490 seconds) and give the feel I desired.  The fog in the sky took care of itself and I walked away with a balanced ethereal image that I just loved creating! Another example of this is shown in the image below.  This again was a super foggy day so the need for detail in the fog was unnecessary so the oly ND needed was again the X4 15 stop magnetic filter!

Nags Head Pier in super dense fog.  X4 15 stop solid magnetic filter for 10 min



Ok, let’s take a look at a problem image where the sky has detail that you can see but when you only use a solid nd the sky is totally blown out!  What you simply need is a X4 Soft Grad filter to balance the sky and water to give you a bit of detail in the sky!

Duck, NC boardwalk and Tdock (broken) with a X4 6 stop magnetic filter plus a X4 2 stop soft grad ND on the sky down to the horizon.

These last two images show a extreme case of no balance between the water and the sky and more nd was needed on the sky to correct the imbalance.



P

Pier, Outer Banks, 12 min exposure, 15 stop X4 magnetic filter and a 3 stop X4 soft graduated filter down to the horizon.  The sun was up to the right and lighting the bottom side of the clouds.

Ok, one last thing… I had a live group hangout last night with some of my online students and we discussed everything in this post but with more info and thoughts on choosing the correct ND filters for a number of scenes.   Here is the link:

https://youtu.be/_qFkUJZzXmw

I know that this has been a long post but it was necessary to show the technical side of creating pleasing long exposures.    Next time I will discuss how to meter for long exposures.

As always please let me know what you think!



















Feb 7 2019

Learn the art of long exposure at our Georgia Coast Photo Workshop!


Georgia Coast Photo Workshop

March 7 – 10, 2019

Boneyard on Jekyll Island at sunrise

I LOVE working with long exposures…

There is so much peace in the long exposure process. At the scene, behind the camera and the results after processing simply takes my breath away. It does not matter what you decide to shoot with, Color, B&W, IR or Film because It simply does not matter, It all works. The processes of working with LE is that as we slow down the shutter of the camera we too are forced to slow down our mental process and be drawn into the scene! This works for boneyard shots at the beach, moving clouds over a building or simple rocks in the surf, It is an amazing journey in one single shot!

THE AMAZING IS POSSIBLE!

That is the thing about coastal Georgia. there are so many amazing photographic opportunities. Aside from the biggies, You all know how I love working in film and wabi/sabi, but creating long exposures is the one single photographic technique for me that always brings me peace…

This is your chance to learn the process, from artistic vision, choosing the correct filters and camera settings to post processing! Come along and learn all of these and more with Jamie and I. You will not be disappointed.

What exactly is needed in terms of equipment?

There are some equipment requirements for long exposures and as you find your self drawn into the process you will likely expand your catalog of gear, especially filters!

  • Good steady tripod.
  • Remote shutter release (wireless allows you to move around while working)
  • Fresh full battery.
  • Camera that allows a T or B mode
  • Low ISO capability
  • A basic set of screw on solid ND filters.  These will work during the day time when the sky and foreground are the same brightness level.  For times around sunrise/sunset you will need to add  2 basic graduated filters as well. ND filters are like sunglasses for your camera that come in different densities (darkness values).

My solid set includes:

  1. 3 Stop X4 solid magnetic Breakthrough
  2. 6 Stop X4 solid magnetic Breakthrough
  3. 15 Stop X4 solid magnetic Breakthrough
  4. Polarizer X4 filter magnetic Breakthrough
  5. Night Sky X4 filter magnetic Breakthrough



My square (75mm and 100mm) set includes:

  1. 10 Stop 100mm X4 solid Breakthrough 2.5 Stop 100mm  soft edge graduated Lee
  2. 3 Stop 100mm X4 Reverse graduated Breakthrough
  3. 2 Stop 100mm X4 Soft Graduated Breakthrough

There are many makers of ND filters, I have always gone with B+W  and Lee but the Breakthrough  are much higher quality with a much higher cost. Because I have recently added a Fuji Medium Format digital system I am building a set of the Breakthrough filters in both solid and graduated using both their new magnetic system and the 100mm square filters for the graduated.

To start, you do NOT need all of these and the basic set will allow you to get started but you will run into trouble as the sun approaches the horizon on sunrise/sunset.

Learning how to use all of these filters is not difficult but you will be miles ahead of everyone if you consider a workshop that covers all of it PLUS the art of post processing your long exposures after capture.  The Georgia Coast is a great place to do just this.  We will be out all day learning behind the camera as Jamie and I wander around with you helping along the way, sharing our secrets for in camera, as well as the art of post processing in evening classes at the hotel!  This is a great workshop to learn the technique of long exposure but not limited to that!  We will spend time at a lighthouse, a old broken down building, piers, beaches and of course AMAZING SHRIMP BOATS!

Another view of the boneyard after sunrise!

You can download a PDF info link here:

https://app.box.com/s/qcw6ekysxgbe8tm8hb1l7a6nfytinly0

Aug 6 2017

Testing the New Kolari Vision AR 720nm Screw On Filter


720nm Medium Format Film Photography with Rollei IR400 Film



Tomotley Plantation in 720nm Infrared with Rollei IR400 film and the Kolari Vision 720nm Filter

Infrared FILM photography has always been on the difficult side, but not because of lack for film because there are several films on the market.  Rather it is due to the poor quality of the available 720nm filters on the market.

Kolari 720nm FIlter

Recently Kolari Vision www.kolarivision.com has come out with a new series of infrared filters with their AR (anti reflection) that stop or greatly reduce hot spots in the center of your film or digital sensor.  These hot spots are due to the various coatings, paint and other reflective coatings on the glass elements and coatings on inside of your lenses causing the light to bounce back and forth several times then hit the film dead center causing the hot spot.

The main filter on the market has been the Hoya R72 filter which works but gives a low contrast washed out image.   Along come the new Kolari filter and now I am getting more contrast and even images with greatly reduced hot spots.  AMAZING!

So lets take a look at the image above.  This is the Tomotley Plantation about 20 min west of Beaufort, SC and  was taken with the Rollei IR400 film rated at 720nm.  Without a IR filter the ISO is 400 and the emulsion generates a very good likeness of Kodak TriX 400 film.  If you add the 720nm filter the ISO drops down to 12 or 6  but you get the amazing whites on the grass and leaves.  You even get the Wood Effect where the green items BLOOM  out with an etherial soft white energy on the image!

Few things beat a beautiful sunrise photographed in color when you want to create a dramatic image. The same scene photographed in infrared may be disappointing unless there’s some  IR reflective subject matter (we’re talking about deciduous trees here) to add interest. That’s because of the “Wood Effect,” which is the bright, white reproduction of the chlorophyll layer of deciduous plants. The effect is named after infrared photography pioneer Robert W. Wood (1868-1955) and not after the material wood which does not strongly reflect infrared.

Normally the Wood Effect is difficult to achieve at 720nm and is better seen at 800nm and and above.  I have been very happy with this new filter from Kolari in combination with the Rollei IR400 film because I am constantly getting the effect plus deep contrasty images.  It simply works as expected which is way more than I can say for others on the market!

Technical Data:

  • Fuji GF 670 Medium Format (120) folding Rangefinder with a Voigtlander 85mm Color Scopar lens.
  • Kolari 720nm AR filter
  • ISO at 12 and 6, both are close to perfect because they are only 1 stop apart.
  • Aperture: f/32
  • Tripod mounted

Development:

  • Ilford Perceptol Stock mixture 1:0, 20c, 14 min with 5 seconds of agitation every min.
  • Water Rinse
  • Stop Bath
  • Ilford Quick Fix for 5 min with 5 seconds of agitation every min.
  • Water Rinse
  • Clearing Wash
  • Water rinse for 10 min
  • Distilled Water rinse with 3 drops of wetting solution
  • Dried overnight in filtered Mistral Drying Cabinet.
  • Wet mount scanned on a Epson 850 pro at 6400dpi.

If you are considering working in 720nm whether in film or digital I highly recommend this new filter from Kolari!



Jul 8 2017

Finding Myself In The Old Ways…


It seems that I am addicted to film…

Miss Lue & A Hungry Egret

I still shoot with digital (A7RII) and love the look and capability of it, but FILM is what I go to every time I go out shooting… It is Terrible and exciting at the same time! It is so bad that I am looking for another freezer to store my excess film stock!

This is (again) Stormy Seas in Georgetown, SC

This is (again) Stormy Seas in Georgetown, SC (perhaps the most photographed boat in the Low Country). I have hundreds of images of it but I am pulled to photograph her in B&W film each and every time I am in Georgetown. There is something about her lines and textures that inspire me to document her life, and I have for years. Yes I will visit ANY shrimp boat (or grist mill for that matter) and each and every time I visit I see something different and unique… Yep addicted!

DATA:

The image was taken about 5 days ago on a 6×9 Fuji GW 690 II using medium format Fuji Acros 100 film and a red filter, developed in Perceptol 1:1 and Wet Mount scanned on a Epson 850 pro. The 6×9 format will give me 8 images per roll and I will usually scan 2 or 3 per roll, but I am very critical and selective because the wet scan process takes about 3/4 hour per scan!

The top image is near Stormy Seas in Georgetown, about 2 blocks away at another commercial dock and seafood house.  I have shot this a hundred times on both digital and film, but never have I captured such a pleasing image  as this.  It is to me a more enriching image full of mood, contrasts and tells a story.  I pleases me to no end the tell the story on an old FILM camera of an old boat and failing lifestyle just as the shrimp boat is in the background and the Egret in the foreground telling a different yet the same story!

There is also the consideration that is tied to the process of working in film.  It is slower and much more deliberate, a truer work of love in that you control every single step of the process…

  • Film choice (Kodak Tmax 100, Tmax 400, Fuji Acros 100 or Rollei IR400)
  • Camera and lens choice (Medium or Large Format)
  • Considering the composition and lines.
  • Getting the exposure dead on (how many of you do that in digital?)
  • Adjusting for contrast and detail in shadows or highlights.
  • Film development and processing for highlights or shadows (another complete immersion of self discovery)
  • Drying (yep at lest 24 hours in a dust free drying cabinet)
  • Choosing the best image for exposure, sharpness, composition, contrasts, lines, dust & hair and so on..)
  • Wet scanning (at least a 1/2 to 3/4 hour project per shot)
  • Cleaning up on the computer by removing dust and hair and adding a bit of contrast)

All in all, the top image took about a week to complete from end to end!  I simply love the process, being immersed in it and becoming one in the creative process.   Yes it is slow but when I am done it is a total representation of MY PERSONAL VISION!

Film is making a HUGE come back in the world of photography!  So much so that you will be shocked when you visit Ebay and look at the prices of old film cameras and systems!   All of the major film makers in the world are increasing their production of films and even Kodak is bringing back discontinued film products!   New film companies like New55, Impossible Project, and FILM FERRANIA have opened up and are making emulsions!

Developing has never been easier, there are many mail order labs out there but you can process your own film in your kitchen with very little effort and investment!  You will need:

  • Dark Tent or changing bag to move your film to a daylight tank.
  • Daylight tank (I reccomend a Stainless Steel tank with steel developing reels by Hewes)
  • Distilled Water
  • Developer ( I recommend Perceptol by Ilford)
  • Stop Bath
  • Fixer
  • Wash
  • Water Rinse
  • Distilled water rinse with wetting agent
  • Clips to dry your film in your bathroom shower
  • A flat bed scanner like Epson 500, 600, 700, 800 or 850)

Total you are looking at about $120 for everything accept the scanner!   There are great videos on Youtube that will take you thru every step in the process!

Tybee Island Light, Kodak Tmax 100 FIlm on a Fuji GW 690 II camera.

The image above of the Tybee Island Lighthouse was taken last month on Kodak Tmax 100 rated at 50 ISO  on the 6×9 format medium format Fuji System.  It was hot and the area full of tourists, even up on the top of the lighthouse itself!  Still the act of creating this image was both fun and fulfilling and I walked away with exactly what I envisioned as I stood there looking at the scene!

I especially love shooting with Medium Format cameras.  They are easier to travel with and the negatives are large enough to give amazing prints.  I do have 3 4×5 large format cameras also that are great fun to you but as you can imagine, they are difficult to travel with.  Once in a great while I will shoot with a 35mm camera, usually smaller rangefinder that were sold in the 60’s and 70’s!

Medium Format:

  • Fuji GF 670 (this is my travel camera in 6×7 format with a 85mm lens that folds up into a thin light camera)
  • Fuji GW 690II (this is a 6×9 format camera with a 90mm lens and a bit larger and better built than the GF camera)
  • Fuji GW 690 III (a newer version of the 690II)

Large Format:

  • Shen Hao 4×5 Cherry Field Camera with 5 lenses and film adapters for also using 120 film.
  • Polaroid 900 converted to 4×5 with a 150mm Fujinon lens.  Think of 4×5 travel camera!
  • Polaroid 110B converted to 4×5 with a 90mm Schneider Angulon lens, again travel!

So, while film does indeed require much more effort over digital, the results simply cannot be compared.   These medium format negatives have a native resolution to create a 71×53 inch print without upsizing it at all!  The amount of detail is simply stunning and more importantly (at least t me) is the fact that the process become a Zen like activity in creation!

I hope that you enjoyed this post but more importantly to me at least that you considered my words on the creative process and taking complete control of it!











Jan 29 2017

Become the Master of your craft….


Pelican Dock - Type 55 4x5 Film, Wet Scan

Pelican Dock – Type 55 4×5 Film, Wet Scan



This is the Pelican Dock on Pawleys Island, SC. It is a 4″ x 5″ FILM image taken  on Polaroid Type 55 film from one of my film workshops.

Polaroid 900 w/ 150mm Fujinon lens converted to 4x5 by Steven Icanberry.

Polaroid 900 w/ 150mm Fujinon lens converted to 4×5 by Steven Icanberry.

I did this with a Polaroid 900 converted to 4×5 format camera and the film was expired (16 years) Type 55 instant 4×5 film that also creates a fragile negative which was scanned Wet Mount on an Epson 850 . This single image costs about $35 to create and process!

But look closely at the image, notice the calm peace of the scene, the amazing clarity and sharpness that is a gift when working with large format film, but more importantly, the edge process markings created when working with this amazing film!

But of greater importance than how I created this image is the why…

We all see amazing scenes as we travel through life, but how many of us actually take the time to really experience and feel on an emotional level what we are actually experiencing as we create our art? I watch so many great photographers skitter from scene to scene like a bee to pollen that it leaves me feeling sad.

Let me ask you, “How can you create art that will appeal to your viewers on an emotional level if you yourself refuse to slow down long enough to feel the emotional impact yourself as you create it?

The key here is to stand before the scene and take it all I. Get a feel for what you desire to share with your viewers before you even pick up your camera! SLOW DOWN, take your time, investigate it from many angles and exposures. Yes this is a single image, in fact the only one I took due to the cost, but I spent a half hour studying the scene, moving around looking for the best impact and knowing that I would get the edge markings and using them to increase overall impact!

This is a hard lesson to learn and harder still to practice. This is one of the the lessons forced upon us who still shoot film as I do. After all, Film = $. We have to slow down and make every shot count so the next logical step is to connect on an emotional level with your subject and thus create art that is charged with mood that will draw your viewer in.

Just because I use FILM as an example here for you do not think that it does not apply to digital!  Yes, once you pay back the investment of your digital equipment with image sales (you do sell your work don’t you?) the cost per image is basically paid only in terms of your time.   But time also has a value and if by slowing down and imparting emotional impact in your image then you will be on the true path of photographic nirvana!

Take your time, explore your scene, feel it’s emotional impact, SLOW Down!

Do not copy the Bee, rather strive to be a master of photography…

Jan 23 2017

Using M mount glass on the Sony A7rii camera


The AMAZING just got better….

Stormy Seas with the Voigtlander 12mm Ultra Wide Heliar M Mount Lens and the Techart Auto Focus Leica to Sony adapter

Stormy Seas with the Voigtlander 12mm Ultra Wide Heliar M Mount Lens and the Techart Auto Focus Leica to Sony adapter

Look closely at the image above.  It was taken with a Voigtlander M mount 12mm Ultra Wide Heliar lens and the Techart M to FE AUTOFOCUS adapter on a Sony A7rii camera. The cleat on the bottom right is about 6 inches from the front of the lens!  The color rendering is amazing and there is very little distortion that is normally found with an ultra wide lens!   I can hear you asking how I accomplished this!

I recently picked up the Techart M to FE Sony mount adapter for my Leica and Voigtlander lenses.  It has been my desire to use them on the Sony A7rii, A6300 and A6500 cameras.

The Techart auto focus adapter is amazing. I actually moves the lens in and out to get a sharp focus.  It has several rules that you must follow to use it and as long as you do it will provide great service.  It is quite fast!

  • Use a center focus point on the camera
  • Set your camera aperture to f/2 and leave. It there
  • Set the real aperture directly on the lens.
  • Don’t try to focus with the lens set to f/22, keep it around f/8 or f/11
  • The Exif data will shot f/2 but the exposure meter will correctly meter the subject.
  • Don’t try to use a heavy lens on the adapter unless you support it.

12mm Voigtlander M lens with the Techart autofocus M to FE adapter

12mm Voigtlander M lens with the Techart autofocus M to FE adapter

Here is a link to a short video demonstration of the Techart M to FE adapter on my Sony A7rii:



B&W work with this lens as well as my other Voigtlander and Leica M mount lenses are just as sharp weather in color or monochrome!

Stormy Seas with the Voigtlander 12mm Ultra Wide Heliar M Mount Lens and the Techart Auto Focus Leica to Sony adapter

Stormy Seas with the Voigtlander 12mm Ultra Wide Heliar M Mount Lens and the Techart Auto Focus Leica to Sony adapter

I also have and use a Metabones M to FE adapter which gives the same results but with manual focus only.   Sometimes manual focus is necessary depending upon your subject but reguardless of focus type both adapters and all of my M lenses work wonderfully on the A7rii camera system!

Stormy Seas with the Voigtlander 12mm Ultra Wide Heliar M Mount Lens and the Techart Auto Focus Leica to Sony adapter

Stormy Seas with the Voigtlander 12mm Ultra Wide Heliar M Mount Lens and the Techart Auto Focus Leica to Sony adapter

If you have a selection of M lenses then the cost of a M to FE adapter is well worth the money.  But I am VERY impressed with the new autofocus adapter!



Please let me know what you think!

























Dec 11 2016

One Perfect Image…


Sometimes we just have to stand there taking it all in!

Hoodoos in Bryce National Park at the Sunset Point Overlook. Olympus XA with Kodak Tmax 100 film. This is MY defining image for my entire trip!

Hoodoos in Bryce National Park at the Sunset Point Overlook. Olympus XA with Kodak Tmax 100 film. This is MY defining image for my entire trip!

Ahh, have you ever had one of those defining moments in life where you KNOW that you are witnessing something truly special that touches your soul?   Well that is exactly what this was for me.  We had been on the road for almost 11 days on a trip from Rapid City thru Wyoming and Utah.  Our last stop of the trip was supposed to be in  Zion National Park but we had to cancel due to terrible rain and flooding in the park.  We extended our time in Arches which was really nice but it was not until I stood here in Bryce National Park at the Sunset point looking down into the canyon that I realized that I had made a mistake… I should have added onto the time there.   We only had ONE day to explore Bryce and it was very nice there with many great vistas and rock formations, but this image at the Sunset Point was the defining moment for the entire trip for me.

Hood Valley, Bryce Canyon, Sunset overview.

Hood Valley, Bryce Canyon, Sunset overview, Sony A7rii

Understand, that I am NOT talking about either of the  photographs captured and shown above, but rather the moment for me personally standing there taking it all in, becoming one with the scene, no camera, no thoughts of photography only the experience and impact of witnessing the greatness of the scene.   I stood there for a good half hour drinking it all in and I will remember the emotional impact upon me for the rest of my life.   Yes… it was that powerful.

There is some serious food for thought in this last statement.  In these days of rapid fire digital photography don’t you think that we can quickly loose sight of what it is that we are trying to create in our art?  Shooting in film slows you down which aids in the creative process.  This is not to say that we cannot do this with our digital systems because we can and I do, but rather most of us who practice this art tend to “hurry, capture and move on to the next thing!”

Olympus XA 135mm

Olympus XA 135mm

It was almost as if it was an afterthought that I actually took my Sony A7rii with me up the trail to the overlook and took a few images which were actually quite nice in color, but after the sensory overload of the scene I could only think of one thing, B&W and FILM.  Yes, I could convert the color image above to B&W in post processing and do quite a good job of it but NOTHING can compare to what I can create with film!  So, it was a bit of a walk back down to the car where my wife and 7 year old grandson were resting because of the long drive to get here, but down I went with only one task, to trade the digital for a TINY B&W film camera, the Olympus XA.  The XA is the worlds smallest 35mm rangefinder camera. It has an amazingly sharp lens with easy focus, but the key is the fact that it is pants pocket (not those bulky cargo pockets but regular ones), it is light and handy.

I took so much camera equipment on this trip that the only space I had for a film system required that it be tiny.   Against all of my experience I threw in this tiny camera along with just 5 rolls of Kodak Tmax 100 film and off we flew.  I am so glad that I did now but having said this it is only fair to share that this was a colossal mistake.  I should have made room for a medium format (120 6×7) camera and taken out a lens or two for the Sony.   I have learned my lesson and will never repeat this mistake.  Don’t get me wrong, the XA captured an amazingly detailed and  sharp image. I love how it turned out.  The Kodak Tmax 100 film along with the Perceptol developer generated a image (yes small) with tiny grain and great sharpness.  Am I happy with the result?  You bet!  Would I have been happier with a larger 120 negative, OMG YES!!  Can I have a do over please?  Yes, I know, not to much of there ever being a chance for that.

So lets sum this up a bit shall we?

  • SLOW DOWN,  take the time to really look at your subject!  If you do this your chances of creating a world class image will greatly improve.
  • Look closely at what is in front of you, take the time to feel its emotional impact upon you and only then bring out the camera and with your skill and insight to the scene make the camera (nothing more than a tool) capture what you saw!
  • Think in both color and B&W.  Remember though that B&W removes the clutter and confusion of normal color work.  In my opinion, B&W allows you to capture the soul of the scene! So yes, take color but also take B&W, you might be surprised at how well you can do.
  • If you are working in digital only, during post processing work color first completely, save the image THEN process for B&W generating all of the mood that you possibly can!

Ok, this post is done.  Get out there, shoot and create, but slow down and think about what and WHY you are doing it!

Nov 22 2016

Going Home to Mama…. Returning to Film!


The joys of returning to our photographic roots…

Pier

Murrells Inlet Fleet, Polaroid Type 55 4×5 film, Wet Mount Scan

Have any of you considered film photography?

There is something about working with film that is very calming which can center one’s soul allowing you to really connect with your art. For me it was like going home to Mama.  The feeling of working with your hands as part of creating your art will make it more involved and enable you to to really influence the hidden nuances in your work. It will add a bit more complexity to your workflow but trust me it is worth the effort.  The single largest change is forcing you to slow down in your creative process, it forces you to really consider every part of your workflow. It really is not any more difficult than digital photography, but it is a bit more involved.

Polaroid 900, Tmax 100 4x5 @ 64, Perceptol

Polaroid 900 with a Fujinon 150mm lens, Tmax 100 4×5 @ 64, Perceptol 1:1 developing

Take a really close look at the details in this image, click on it and look at it in the full screen mode.  Look at the GEARING on the edge of the wheel.  The detail there will take your breath away!

Film Cameras

Olympus XA 135mm

Olympus XA 135mm

I have way too many film cameras to list them all, some really small like the Olympus XA which is the worlds smallest 35mm rangefinder and a joy to use.

I also have an Olympus RC 35 camera that is another fixed lens rangefinder. It is simple and fun to use and can be found for very little money.  I have mine rebuild and given a bright blue suite that suites it quite well!

My Custom Olympus 35 RC Film Camera, one of dozens of film systems I shoot.

My Custom Olympus 35 RC

My Leica M7 Film Body

My Leica M7 Film Body

My last 35mm camera system is a Leica M7 system. It has interchangeable lenses and is one of the best built camera systems that I have.  Couple it with the world class Leica lenses and you have an unbeatable 35mm system.

Confusion, Petri 7S 35mm, Eastman XX flim

Confusion, Petri 7S 35mm, Eastman XX flim

Fuji GF670 Medium Format

Fuji GF670

Fuji GF670

Fuji GF670

Moving up to Medium Format 120 film systems I have three.  I have the Voigtlander Bessa IIIw system that is 6×7 format and the Fuji GF670 camera (also sold under the name of Bessa III) with a longer 85mm lens (left & right). The 670 is my medium format travel camera of choice.  Not only is it a functional camera with a built in meter but it is attractive and it always will draw a crowd when I get it out to use! Another nice point to the GF670 is that it folds down on itself to a thin easy to store camera in your bag!

Mamaya RZ Pro II system

Mamaya RZ Pro II system

And lastly the Mamaya RZ Pro II SLR ( Right) with interchangeable lenses and a world class metering system. This camera is large and heavy but easy to use and a very powerful camera system! I have a f/4 65mm and f/4 180mm lens for it.  I also have both the waist level finder and a metering prism with spot and matrix!  Like I said, heavy and big, but I use it for ultra long exposures on the coast with the Fuji Acros 100 film which has almost NO RECIPROCITY failure up to 140 seconds then only 1/2 stop after that!   The film base is a little on the thin side but still my film of choice for long exposures.

Stormy Seas, Fuji GF670, Tmax 100, Perceptol 1:1, Wet Mount Scan

Stormy Seas, Fuji GF670, Tmax 100, Perceptol 1:1, Wet Mount Scan

Beautiful!

Polaroid 110 with 90mm lens converted to 4×5!

My 900 converted to 4x5 by Alpenhause Kamera Werke

Polaroid 900with 150mm Fujinon lens converted to 4×5

Moving up to 4×5 Large Format cameras, I have three. first I have a Shen Hao cherry field camera.  Functional as it is beautiful.  I rarely take it out, rather I am using a Polaroid 900 converted to 4×5 with a Fujinon 150mm lens and a Polaroid 110B camera converted to 4×5 with a Schneider Super Angulon 90mm lens.  It is a beauty and very wide!

Yes, as you may have noticed, some of these cameras are quite large.  This is due to the negative size.   Let me give you some idea as to why digital cameras can never come close to the resolution of film.

Focus Test - Epson Wet Adapter Across 100 Perceptol 1:2 Springmaid Pi

Montreat Cascades, 4×5 Tmax 100 developed in Perceptol and wet mount scanned.

Lets start with medium format:

  • Medium Format 6×7 format makes an image 2 1/4 inches tall and much wider.  Scanned at native resolution of 6400 dpi on an Epson 850 Pro scanner gives me a file resolution of 16452 x 19668 dpi or a print size at 300 dpi of 4.5 feet by 5.3 feet!  This is huge.
  • Large Format of 4″ x 5 ” scanned at 6400 dpi (native) gives a file size of 29107 x 36070 dpi or a print size of 8 feet x 10 feet!  There is not a digital camera system in the world that can come more than a small fraction of this!

Film

Film has turned wildly popular again in the past several years and many of the big film manufacturers have started increasing their film production lines again. This is especially true in the medium format lines (120) and 4×5 large format films! Film can be found in single rolls or in bulk almost everywhere again.  The big box companies like B&H, Adorama and many others carry almost every type and format that you could ever want!

Processing in B&W has never been easier at home with eco friendly chemistry with no darkroom needed. Only an initial outlay of around $150 will get you started. Cameras can be found anywhere for next to nothing!  You will need:

  • Dark Bag, a cloth bag that it light proof with arm sleeves that enable you to put your film, developing tank, reel an lid inside with your arms to move the film into a light tight developing tank!
  • Developing Tank, I recommend a stainless steel version.
  • Film Reels, I like the Hewes stainless steel ones.
  • Developer, comes either in a powder or a Liquid.  I like Perceptol and/or Rodinal R09.
  • Fixer, to remove un-used silver
  • Liquid wetting agent to prevent drops to dry on your negative.
  • Clips to hang you film up to dry!

You can scan your film into your computer with a good Epson scanner like the 700, 750, 800 or 850.  You can also buy an adapter for your camera allowing you to scan by photograph!

While I work in both color and B&W, digital and film I find time after time I pick up a film system and load it up with a good B&W film. The process of developing your film can really help you connect to your work as well.

I like several films, here they are in order of favor:



  1. Kodak Tmax 100 in 35, 120 and 4×5, very small grain, good dynamic range easy to process
  2. Fuji Acros 100 in 35, 120 and 4×5, very small grain, good dynamic range NO RECIPROCITY FAILURE, easy to process
  3. Rollei IR400 in 35, 120 and 4×5, Infrared or normal B&W, good dynamic range, easy to process
  4. Rollei Retro 80S in 35 and 120, amazing clarity and sharpness, good dynamic range easy to process
  5. Eastman XX in 35, motion picture film used in B&W movies of the 50’s, smooth gradient transitions.



As an example here is the top image from last week of the fishing fleet taken on 20 year out of date Polaroid Type 55 monochrome instant film. The camera is also a Polaroid 900 that my daughter sent me years ago from a garage sale that I had converted to 4×5 with a Fujinon 150mm lens. A MOST beautiful camera in a bright new blue suite that is just fun to use. It is both rangefinder and ground glass focusing that forces you to slow down and really consider each and every image you capture!

The Type 55 film, even outdated, works flawlessly and generates amazing images where the edge markings add to the artistic impact of your subject

Pelican Dock - Type 55 4x5 Film, Wet Scan

Pelican Dock – Type 55 4×5 Film, Wet Scan

So what do you think?  Are you tempted to try this out?  It is easy.  For starters, you can look at the continuing education departments at a local college or hight school.  Most offer B&W film photography with darkroom work.  This will teach you enough to allow you to determine if you would like to further investigate this wonderful medium!

You can also contact me and request info on one of my film workshops held in Pawleys Island SC.  I would love to have you and share this amazing link to our past!

Please let me know what you think of this post!

Sep 3 2016

My Thoughts on the Art of travel photography…


Or… What I Did On My Summer Vacation!

Warning, LONG post…

Canyon Lands Pano, Sony A7rii with the 24-240 and polarizer

Canyon Lands Pano, Sony A7rii with the 24-240 and polarizer


Devils Tower

Devils Tower

Travel Photography… Say it, let it roll off your tongue, think about it!  I bet that the first thing that comes to mind are images from National Geographic, fine, super saturated color photographs that could take you anywhere in the world by simply looking at them!  You know the kind, they enabled you over the years to travel vicarisly around the world just with the magazine and its images!

But is that what travel photography really is?



What is the intent of travel photography  to document a place or a trip?  Is it designed to tell a story on an individual level or to the masses?

A6300-3886- S1_500-Whodos Bryce-2016 1 copy

Well for me, it is a combination of the two.  Most importantly, the images are to refresh the memories of the trip.  But there is a real market out there for well done travel photography whether in print publications, web, advertising or fine art prints.  It can be quite profitable if you work at it and can step back and look at your own images in terms of the above markets.  Even the housing deceration market has room for this type of photography provided that you can simplify your work to show colors and contrasts over locations.

Jordan, My 7 year old photographer grandson

Jordan, My 7 year old photographer grandson

For this trip, and pretty much all the time when I am shooting digital, I exclusively use the Sony 42 mpix A7rii camera system and the new Sony A6300 for high speed work with Sony G lenses or Sony Zeiss lenses. They are very well suited to this type of photography and give you enough (42 mix)  resolution to get amazing images yet still have room to crop!

The drive for this post was a recent  two week trip out West with my wife and 7 year old grandson Jordan who I am teaching film photography and darkroom processing to (photographically, I had grand plans for him this trip).  Given time I plan on turning him into a photographic GOD for something fun while making sure he is a Rocket Scientist!

We flew into Rapid City, SD and picked up a one way rental car and our first night in a long string of hotels.

Devils Tower

Devils Tower

Our Itinerary:

  • Prairie Dog

    Prairie Dog

    Day 1. Rapid City layover and rest.

  • Day 2. Pick up rental car and drive to Mt. Rushmore in the morning and then the Devils Tower in the afternoon. Continue on 1/2 way to Codie, WY.
  • Day 3. Famous Hot Springs of Thermopolis, Wyoming then an afternoon visit and guided tour to the most successful dinosaur dig on our continent.
  • Day 4. Codie WY for several stops including the famous old west town and the Codie Rodio.
  • Day 5-7. Yellowstone for 3 days in a park lodge.
  • Day 8. Leave Yellowstone, drive thru and stop along the way in the Tetons finishing in Jackson WY.
  • Day 9. Drive just north of Salt Lake City in the town of Herbor for a 3 hour train ride around the valley.
  • Day 10-12. Drive to Moab for 3 nights and visit Arches and Canyonlands National Parks with extra boat and jeep rides thru the park as well as Dead Horse Point State Park.
  • Day 13. Early morning drive to Bryce National park for 2 days of Bryce National Par
  • Day 14. Drive to Salt Lake for flight home on day 15.

Drugstore of the West, Cody, WY

Drugstore of the West, Cody, WY

So as you can see there was a well thought out family plan for travel and location visits!  But, I also had a plan, my photographic plan!

So lets talk first about my TRAVEL photographic equipment plan.  I wanted to travel light (yea right).  No backpack, rather a small rolling camera case that would fit into the over head of a small commuter plane so that I would not have to check it.  I would not have room for a film camera… Dang!

So here is what I brought along:

  1. Sony A7rii camera body
  2. Sony a6300 camera body for Jordan
  3. Sony 24-240mm one lens does it all for Jordan
  4. Sony 24-70 Zeiss f/4
  5. Sony 70-200 G f/4
  6. Tamron 150-600 for those exotic animals I expected to see
  7. And yes… A Olympus XA 35mm film camera (but it is the worlds smallest rangefinder) with 6 rolls of Tmax 100
  8. Filters, ND for long water falls and polarizers for all of the rest in 67mm and 72mm.
  9. Batteries an chargers (both cameras used the same)

This was a good plan (or so I thought) until our very first stop at Mt. Rushmore where Jordan informed me that the 24-240 was too long and heavy.  Oh well, I took that and gave him the 24-70.

RULE ONE:   No camera plan survives first contact with a 7 year old!

Ok, so at least the part of the photographic plan of me being able to NOT check my camera equipment worked! (I did put all of my insulin and supplies in the camera case just to prove my need to have the case with me but did not need it).

RULE TWO: A super  zoom really works best when you have to carry lots of glass around while traveling.  See Rule One, Jordan did me a favor here!

Yes, I know that one would not normally trade a light 24-70 Sony/Zeiss f/4 lens for a 24-240 f/3.5-5.6 Sony super zoom but I have to be honest, I was VERY impressed with the super zoom!  It was not really that much heaver but it was longer. I NEVER put on the 24-70 after that.

Things to look for on a cross country western trip:

  1. Wildlife
  2. Landscapes & Vistas
  3. Unique rock formations
  4. Waterfalls
  5. Wild colors
  6. Unique photographic visions

Trip Highlights!

Yellowstone

Old Faithfull

Old Faithful

Querimony: To Questionably Moan & Complain!

I expected great things of Yellowstone and that showed in the number of days there as well as staying in the park.  Yellowstone is HUGE, so much so that you have to allow for HOURS of driving time from location to location.  The roads are all good, 2 lanes with adequate pull offs.  BUT having said that there are rules of behavior in pulling off and rules for how you treat the wildlife.   I cannot tell you how many people (especially foreign visitors) who would jump out of the car (still in the road) and run off into the fields right up to the wildlife.  To say that this is bad behavior is an understatement.  It for one, keeps others from being able to photograph the wildlife and two puts the peoples lives in grave danger that approach the wildlife!  Yet this happened almost every time wildlife was near the road.  The park rangers had simply given up on trying to educate people who would not listen. They spend most of their time dealing with the MANY dreadful traffic accidents that happened every day.  The traffic jams were terrible whenever an animal was near.  Sometimes this was due to the animal being on the road but most of the time it was because people parked right in the middle of the road who left their cars.

Buffalo on the Yellowstone

Buffalo on the Yellowstone river in the early morning mist

I am going to share a few of my favorite images from Yellowstone with you.   It is a good cross section of what you can expect to see while visiting!



Blue Pool, Prismatic Spring Yellowstone

Blue Pool, Prismatic Spring Upper Yellowstone



Prismatic Spring Yellowstone

Prismatic Spring upper Yellowstone



Yellowstone Antelope

Yellowstone Antelope, North Entrance



Teal Pool, Upper Yellowstone

Teal Pool, Upper Yellowstone

And last….



Lower Yellowstone Falls Detail

Lower Yellowstone Falls Detail 1 second  Exposure with 10 stops of ND

I would travel again to Yellowstone but in the spring or fall in order to see more of the wildlife there.  I realize that in the heat of August even the animals would move to higher locations in order to reduce the heat.  The only wildlife I really saw in abundance on this trip were Buffalo, Elk and Antelope.

Moab, Arches & Canyonlands National Parks

Delicate Arch

Delicate Arch

The Moab area offered some of the most amazing locations of our trip.  I had thought that nothing could beat Yellowstone, but Moab came very close.

Sandstone Arch, Arches

Sandstone Arch, Arches

There are 3 offerings here, the Arches National Park, Canyonlands National Park and the Dead Horse Point State Park.  ALL three are must see locations.  For me Arches was the best, but honestly, we spent time exploring all three in detail (well sort walk detail).  We also paid extra for a boat trip on the Colorado River thru Canyonlands for a low view and a back country jeep tour to see area and arches not available to the general public in Arches!  If you get here I advise that you do both side trips.

Courthouse Rock, Arches

Courthouse Rock, Arches



Whale Tail Arch, Backcountry Tour

Whale Tail Arch, Backcountry Tour



Windows Arch on the Back Country Tour, Arches

Windows Arch on the Back Country Tour, Arches



Dead Horse Point

Dead Horse Point. Look at the lower left corner 1/3 up to see the dead horse outline.



Canyon Lands, Isle in the sky

Canyon Lands, Isle in the sky



General Utah



High Desart Train Pano

High Desart Train Pano

So…. I had this vision stuck in my head of a parked line of freight train box cars parked in the high desert with a mesa behind them.  I found myself looking to the sides of the car as we traveled endless miles through Wyoming and Utah.  Finally my wife asked me what I was looking for and when I told her she made a point to help me look and stop me when we came upon them.  I know that out West there are ultra long stretched of road.  Most are 4 lanes with lots of traffic.  If you see that special scene make sure that you safely stop so as not to irritate the 7 year old in the back seat, pull safely off to the side of the road as you watch for the perfect compositional setup and get out and shoot it!  DO IT!

Because…

RULE THREE:   There are NO GO BACKS!  If you see a subject or scene on the side of the road immediately stop and shoot it!

Bryce National Park

Whodos in Bryce Canyon

Whodos in Bryce Canyon

To say that Bryce National Park is anything less that amazing is an understatement.  It was right up there with Arches and Yellowstone in amazing views, colors and the wow factor!  This is the location that I would choose to visit again to try some different styles of photography.  The colors of the Hodoos are simply amazing and full of wild colors and contrasts.

Natural Bridge Bryce

Natural Bridge Bryce

RULE FOUR:   Revisit those scenes and compositions as many times a possible!

While in Arches, my 7 year old grandson decided that he had enough nature and vistas after driving Arches all day long.  I took them (at my wife insistence) back to the hotel and went back out to Arches and drove it again in different light conditions and the 2nd time there were clouds in the sky.  This made for much better images that I would not have gotten if I did not go back out again!

Final thoughts on what makes travel photography great!

Now as you have seen here, I presented this trip as a travel log.  Attempting to document the many wonders of the high plains in the west. For images that have the possibility of selling you need to:

  • Pay more attention to your editing, scene selection and composition.
  • You must re-visit local scenes several times in order to get the best light and clouds.
  • You MUST shoot with your best equipment in order to produce high resolution images for future publication.
  • In your post processing you must choose only your best images and throw the non used images out.
  • Be your WORST critique and select only what you would consider to be world class images.  Case in point, the image above of the Court House Rocks in Arches.  Yes it is a nice image but the lack of clouds in the sky reduce its impact to the point of it being a weak image!

Hood Valley, Bryce Canyon, Sunset overview.

Hood Valley, Bryce Canyon, Sunset overview.

This type of travel photography is more difficult that personal travel images traditionally done by the millions of photographers who roam the country.   These types of images are still travel photography but basically serve to show and remember your great trips!  They will include more family member in the scenes, less care about the total compositional elements because those are simply not as important to the memory of the trip and locations! They are just as important, but will not generally generate income from sales and publication.

Colophon:  Very Important Lessons Learned:

  1. NEVER, and I do mean NEVER plan a 14 day photographic trip with a 7 year old and expect him to be excited beyond the first week.   I would have been better off leaving the A6300 and 24-70 f/4 at home thus lightening my load and giving him MY camera when he desired to take a photograph!
  2. Make SURE that you explain to the said 7 year old that “NO!  There are places that not only will there be no TV but also no internet!  (I was able to get around this most of the time with my iPhone as a hot spot for his iPad!)
  3. Build in several fun days (as viewed by a 7 year old) that includes things like movies, water parks and so on!  This is a small price to pay for 7 year old mental health and will refresh his young mind and keep it open for those wonderful scenes you travel to!
  4. How can you get those great travel shots when your walking is limited?  As a cranky 63 year old man, make sure that you plan photographic stops THAT YOU CAN DRIVE TO!  We (actually my thoughtful wife) did this ahead of time thus insuring my mental health and happiness at the stops we made!
  5. Take the time to occasionally stop at nice restaurants  that actually serve wine and beer (this will assist with the mental healty of said wife!)  Happy marriages are NOT built and fast food places in a rush!
  6. If you desire to shoot medium format film, you damn well better plan on space for the camera and film!  Regrets upon your return will leave a sour taste in your mouth!
  7. Be flexible, very flexible.  This will leave you happy in the hotel at night!
  8. Take your pain drugs! (See #7)
  9. If you see a photo subject on the side of the road STOP!  There are no go backs! (see RULE THREE about this very thing and really your wife know this and will support your urges to stop in the middle of nowhere!
  10. Wildlife… What wildlife?  How did I miss all the great shots of wolves, coyotes, and bears?  I was in Yellowstone for heavens sake!  The lesson here is to make sure you check the season for high animal activity.  I have listened to my photographer Son talk about so much wildlife in Yellowstone that it was not safe to drive!   I guess he should have mentioned when he was there!  Oh well.  I AM happy with what I actually did see (Buffalo, Antelopes, Elk and Prairie Dogs)
  11. Stop at EVERY overlook in every park.  You will be happier having done so (and vicariously so will your wife).  You will hate yourself when you return home only to have a photographer friend tell you that the one overlook you skipped was the only one you should have stopped at!
  12. If you find a scene that is magical for you revisit at a different time of day.  This is VERY IMPORTANT and promote photographic health for those who have heeded these magic words.
  13. Would I do it all over again with a 7 year old?  YOU BET!!  But I would plan differently.  If I take any of my grandkids I need to remember that it is their vacation as well.  This means that you build in days doing fun stuff for their age also!

Please let me know what you think of this long post!  I welcome all feedback.



Bryce Canyon

Bryce Canyon in camera pano

Jun 12 2016

Testing The Sony A6300


Smaller, Faster and able to leap over tall buildings!

Yes, you are correct, I shoot with the Sony A7rii 42 mega pixel full frame mirrorless camera!  What you cry am I doing with the A6300 which is only 24 mega pixel and an APS-C sensor?  Well friends, the answer to that is simple, well perhaps not…   I envision the A6300 as a 720nm Infrared camera.

Pawleys Island Marsh, Sony A6300 with the Sony/Zeiss 24-70 f/4 and a polarizer. B&W conversion

Pawleys Island Marsh, Sony A6300 with the Sony/Zeiss 24-70 f/4 and a polarizer. B&W conversion Look at the detail in the gate and grass.  This has a 3 dimensional effect!

But it has several very interesting and powerful functions that have engaged my curiosity.  Those are:

  • 11 fps shooting speed.
  • Faster and more accurate focus than the A7rii
  • More focus and metering points.
  • Half the weight of the A7rii
  • Much brighter and accurate focus peaking system.
  • Ability to work macro at 1:1 with live view and not have an over pixelated display.
  • The ability to turn my 600mm lens into a 900mm lens!
Sony A6300 Front View

Sony A6300 Front View

The 4 test images I took today were shot hand held at 1/250s and in RAW with Zone Focusing.  I also had the LIVE VEIW DISPLAY: Setting Effect: ON.  This enabled the camera to simulate the exposure effects during composition to give me an idea of what I am actually seeing.

The A6300 is a TINY camera system.  It is so light (even with a L Bracket installed) that I had to be very careful when carrying it around.  I worried over dropping it and not knowing!

Sony A6300 Back View

Sony A6300 Back View

The camera does NOT have a built in Stabilizing system, rather it relies on the fact that most Sony lenses have that built in.   I has 3 custom WB memories for those of you who are considering the camera for Infrared and it also has 2 custom setup memories that I have found to be very helpful with my A7rii camera!

I found the camera very easy to use and control.  I setup all of the custom functions and buttons to make my life easier when shooting it.

As I said, this camera was meant to be converted by http://www.kolarivision.com into a 720nm infrared system and it may actually meet that end, but I really like the ability of the APS system to give me 900mm from a 600mm lens!





Pawleys Island Marsh, Sony A6300 with the Sony/Zeiss 24-70 f/4 and a polarizer.

Pawleys Island Marsh, Sony A6300 with the Sony/Zeiss 24-70 f/4 and a polarizer.

Here is the color version (with polarizer) of the image above.  The colors are nicely saturated and the overall image is sharp and offers enough detail and sharpness to draw the viewer into the image!

Pawleys Island Marsh, Sony A6300 with the Sony/Zeiss 24-70 f/4 and a polarizer.

Pawleys Island Marsh, Sony A6300 with the Sony/Zeiss 24-70 f/4 and a polarizer.

Here is another view of the salt marsh.  I have to say that the camera with the 24-70 Zeiss lens is easy to hold and control.  The camera control buttons are easy to reach and control without using them by accident.

Pawleys Island Marsh, Sony A6300 with the Sony/Zeiss 24-70 f/4 and a polarizer. B&W conversion.

Pawleys Island Marsh, Sony A6300 with the Sony/Zeiss 24-70 f/4 and a polarizer. B&W conversion.

Lastly, a B&W conversion of the same image.

I am really excited with the functionality of this little system.  I am pleased with the results and will use it for a few months as a color system for my long lens. Ultimately it will be converted to IR but for now I will play with it.

There are several issues with its firmware (same as when the A7rii came out).  Overheating during hight speed continuous shots is the big one but Sony assures me that a fix is in work as it was when the A7rii camera came out!

I will be experimenting with the system for a few months and see what it can offer me in terms of images and use.  Later this week it is going to the beach for some ultra long exposures to see if it has any body light leaks!

What do your think?





Apr 21 2016

Amazing New AR Coated IR Filters from KolariVision.com


Kolari Vision introduces a NEW Anti Reflective IR coating for their conversion filters!

Fuji X100s, 850nm Kolari AR conversion - Under Foley Pier

Fuji X100s, 850nm Kolari AR conversion – Under Foley Pier

I LOVE shooting IR and have a long history with it in both Film and Digital.   I have had over 25 conversions from ALL of the big conversion companies around the country!   But, once in a while I would get a camera that no mater how hard I tried, I will get a hot spot with it or the lenses I used.   You learn how to deal with this by selective use of the aperture but once in a while you would just not be able to get around the problem and loose the shot….

Fuji X100s, 850nm Kolari AR conversion - Shrimp Boat

Fuji X100s, 850nm Kolari AR conversion – Shrimp Boat

Well about 3 weeks ago Ilija from Kolari (http://www.kolarivision.com ) sent me a note telling me about a new coating process for his conversion filters.   I have a long history with Kolari, LDP and Lifepixel but I have never heard of this till now.  Ilija offered to do a free conversion with this newl IR AR coating for me in return for evaluating it in the real shooting world! So I told him that I would send the X100s off as a test camera and that I needed it back fast in order to allow others to play with the camera also!   Off it went on Tuesday.  Imagine my surprise when I got it back in hand the following Wednesday!

Here is what Kolari says about this new AR IR coating:

  • Uncoated glass has a reflection of around 4-5% at all wavelengths, and we found that this reflection off the sensor filter was bouncing off the glass and reflecting back from the lens housing and aperture blades to cause the hotspots.  We developed this anti-reflective coating that is centered around the IR wavelengths that cause hotspots, and reduced the 5% reflection down to <0.5% (see the attached graph for reflection % by wavelength scan, and the picture of the IR filters for the visual difference of IR reflection).
Unknown

  • The coating does not reduce visible light reflections as much, and does not reduce blue reflections at all. This gives the glass we use a blue shine, since that is the only range that is fully reflected still (see picture of black filters).
AR coating test on Visible Light

AR coating test on Visible Light

AR coating tests on BLUE light

AR coating tests on BLUE light

  • I am getting ready with a new website which I hope to launch in 1-2 weeks, so I have not put the coated version of the conversions online yet, but they will be offered on our Full spectrum, two spectrum, 590, 665, 720, 850, and Blue IR/NDVI conversions. There will be a $50 optional upgrade on all of our conversions at this point.



  • I plan on offering only the coated version eventually, but the batch runs are expensive and I cannot coat our full inventory at once. I’m not sure if you are aware, but we stock custom made custom thickness filters for all our camera/filter combinations so that each conversion gets a piece of glass that maintains the original optical distance (refractive index x physical thickness) as closely as possible, which changes for each filter material. Other companies use a few general size pieces of glass, glue them directly to each sensor, and calibrate the focus for an arbitrary lens, which reduces what they have in inventory. Our design choice means that we have around 200 unique pieces of glass in inventory for DSLR and mirrorless cameras, and another 200 for point and shoot models, so you can imagine the challenge in getting them all coated. – Ilija

Fuji X100s, 850nm Kolari AR conversion - Thru The Door

Fuji X100s, 850nm Kolari AR conversion – Thru The Door

So as you can see they are up and almost ready to start filling orders for these new filters.

Fuji X100s, 850nm Kolari AR conversion - McClellanville Fleet

Fuji X100s, 850nm Kolari AR conversion – McClellanville Fleet

I have to tell you that with my test conversion on the Fuji X100s to AR 850nm that ALL of my hot spot issues simply went away.  This camera has always had a tendency for IR hot spots.   I have converted, tried and sold so many IR systems in the past that I have lost count.  I could not, would not sell this one as it is one of my most prized IR systems.  To say that I am pleased with the results of the Kolari IR AR Coating is the understatement of the year!

Remember, if you decide to order from Kolari, give them my name for a $15 discount!



Mar 21 2016

A Little Time Off With The New Sony A7rii Camera System


A personal trip to the West Coast to chase Hummingbirds, Rough Shorelines, Fishing Boats, Light Houses & Elephant Seals!

Light at Santa Cruz at Sunrise. Sony A7rii

Light at Santa Cruz at Sunrise. Sony A7rii 15 second exposure

Yes, it has been a busy year with the start of our workshop schedule!  Add into that a knee operation, taxes and other such negative aspects to life we decided that it was time to take a break!   So, for 2 perfect weeks we ventured out to the San Fransisco area to explore the rough West Coast!

Looking North along Rt. 1. Sony A7rii

Looking North along Rt. 1. Sony A7rii

I know that it has been a long time since I did a post here but the workshop and teaching schedule has been brutal.  It seems as quick as one year ends that another begins and we are busy again!  The good news is that the photo schools are moving along and this years workshops are moving forward.  I have had NOT had any time to work in the darkroom this year yet but hope to fix that soon as well.    Plus the knee repair is finished and I am starting to feel a little better after that!

Sea Lion on a Float. Sony A7rii

Sea Lion on a Float in Monterey. Sony A7rii

So, we decided to take a break from it all and flee to the West Coast to get lost in the rough shore, wildlife and the continued search for old fishing boats!  It was a wonderful trip and I am sorry to say that it is all over and done with but with great photographic results!

Sea Lions at rest... Sony A7rii in Monterey

Sea Lions at rest… Sony A7rii in Monterey, 70-200mm G f/4

This trip was centered on the new Sony A7rii 42 mpex camera body.  As you know I am a dedicated mirrorless shooter and in my quest for the perfect camera I have settled on this system.  It has amazing functionality, SUPER wide dynamic range (14) and a review from DXO as the best and most advanced image sensor ever tested!  I also added the Sony/Zeiss 24-70 f/4, the Sony 70-200 G f/4 and the Tamron 150-600 A lens with the Sony adapter which allows full lens control and auto focus.  I also have adapter for all of my Leica and Contax glass as well but for this trip it is the 3 lenses listed above!

Rt. 1. Sony A7rii

Rt. 1. Sony A7rii, 87 sec exposure, 70-200mm G f/4

We based our home plate in San Jose and then traveled around for the 2 weeks.   Spend most of our time in Santa Cruz because the hummingbirds were there in vast numbers building nests and laying eggs, but more on that later.   We also went north to Point Reyes specifically to photograph the wrecked fishing boat Point Reyes.  But while there spent time with the lighthouse and Elephant Seals!

Lone Cyprus, 17 mile drive, Peeble Beach. Sony a7rii

Lone Cyprus, 17 mile drive, Peeble Beach. Sony a7rii, 70-200mm G f/4

We also went south to Monterey for whale watching and a trip along the 17 mile drive!  The image above is from the Lone Cyprus along the drive.  The drive costs $10 per car but is very much worth the cost.  It is full of wildlife such as birds, deer and seals.  The rugged coast has to be seen to be believed!

The Point Reyes, High and Dry. Sony A7rii system.

The Point Reyes, High and Dry. Sony A7rii system. 24-70 Sony/Zeiss f/4

So then this image I am sharing above is the Point Reyes, a boat washed ashore a while ago.  This boat was suggested to me by my friend Jennifer Hunter who lives in Santa Cruz and was one of my main location visit requirements.  This is in a National Sea Shore North of San Fransisco and was about a 3 hour drive from San Jose.

The Wave.... Sony A7rii. This wave was over 80 feet high.

The Wave…. Sony A7rii. This wave was over 80 feet high.

The WEEK we arrived this boat was burned on its stern by a STUPIDLY UNCARING PHOTOGRAPHER who put his own agenda above the preservation of the scene.  He was doing spark photography with flaming steel wool and destroyed the back.   I hope that the Federal Government (National Park) throws the book at him for this.   I feel very lucky to have walked away with this wonderful shot of this local landmark…

Point Reyes Light. Sony A7rii

Point Reyes Light. Sony A7rii, 70-200 G f/4

Also visited was the Point Reyes Lighthouse!   What a wonderful subject and location.  It is high on a cliff over looking the Pacific Ocean.  It is full of color, depth and wonder!

Elephant Seals, Sony A7rii with 150-600mm Tamron A mount.

Elephant Seals, Sony A7rii with 150-600mm Tamron A mount.

So as you can see, I have LOTS of time to relax and shoot with the new Sony system.  To say that it is an amazing system is an understatement of Biblical proportion! All of the lenses are flawless and gave great results!

Bright Allen's Hummingbird

Bright Allen’s Hummingbird

But Wait!  I have not shared my several trips to the Arboretum at the University of Santa Cruz!  There were hundreds of Allen’s and Anna’s humming birds there deep into the fury of mating season!  They were amazing subjects and since I did NOT bring along my hummingbird flash setup I was forced to shoot the “bird on a stick” portraits.  Still, the results were stunning.  ALL of these shots were taken on the Tamron 150-600mm A mount lens with the Sony A to E adapter.  Yes, it did and would auto focus, but with the birds against the green vegetation it had a difficult time picking them out to focus on.

Allen's Hummingbird

Allen’s Hummingbird

So I shifted to manual focus (yes I said manual…) with white focus peaking.   To say that I was stunned at the ease of focusing with this at high speed still leaves me breathless with wonder!

Super Bokeh: Allen's Hummingbird

Super Bokeh: Allen’s Hummingbird

The Sony manual focus with peaking is simply the BEST manual focus system that I have EVER used!  It was fast and DEAD ON…

Allen's Hummingbird

Allen’s Hummingbird

I will let the results speak for them selves…



I hope that you enjoyed this update and info on the new Sony system.  Please let me know what you think!





Dec 10 2015

How to Adjust White Balance In Lightroom


Another good post from my friend, colleague and student, Rhonda Griscti. Her post this time is on understanding White Balance. A good read to be sure!

My Leica Travels

Why should you care about White Balance? Because a proper white balance is how we get the colors in our images to be as accurate as possible. Why would you need to get the color right in your shots?  You might have noticed when examining shots after taking them that at times images can come out with an orange, blue, yellow etc look to them – despite the fact that when you were taking them the scene looked quite normal. The reason for this is that images different sources of light have a different ‘color’ (or temperature) to them. Fluorescent lighting adds a bluish cast to photos whereas tungsten (incandescent/bulbs) lights add a yellowish tinge to photos.

We don’t generally notice this difference in temperature because our eyes adjust automatically for it. So unless the temperature of the light is very extreme a white sheet of paper will generally look…

View original post 305 more words

Nov 29 2015

Intimate Landscapes


A insightful look into the study of Wabi/Sabi by one of my photographer friends and student! Rhonda is someone that you should also follow as her work will keep you enthralled!

My Leica Travels

Sometimes its the little things that make the difference. As a landscape photographer I am always on the search for the BIG image the WOW image the right light in the right location to make a big impact. But sometimes we need to take a moment to look for the small stories within the BIG image. Those intimate landscapes can create a more personal connection with the location. They have their own stories to tell and are just waiting for the photographer to see them.

I love new locations and rarely turn down an opportunity to shoot something new. But every new location can be both exciting and overwhelming. There s so much to see and what to photograph first? I want to jump in and shoot it all! In that moment I don’t see the details I see the BIG scene and to move from overwhelmed to creating images I…

View original post 1,195 more words

Mar 16 2015

The Purity Of B&W


Going Home To Momma…

Don’t you have the feeling sometimes of not reaching that creative high so that when you return home you are almost like an empty husk?

Well me too, and sometimes I really need to stretch my artistic legs.  Going out with a Color Camera will just not get the job done and leaves me feeling empty.  Working in Film is a lot better and scratches an itch that I just cannot reach otherwise… But when I am really feeling creatively down and mentally cramped I usually turn to my Leica M Monochrom system.

Duggars Creek Falls, Boone, NC. Leica M Monochrome

Duggars Creek Falls, Boone, NC. Leica M Monochrome

Working directly in B&W is a soul expanding exercise that will re-inflate my creative side quickly and effectively.  I am the type of photographer who can actually think and see in B&W. Actually generating those images in the field with a capable B&W rangefinder system really is like going home to Momma.  It leaves me with that ohhhh feeling, or is it OHHHHH… Yep, that is the feeling that I am talking about!

First, I LOVE shooting with a rangefinder camera system.   ALL of my cameras are rangefinders except for one little Fuji XT1 that sits in my camera bag rarely used unless I take it out for lightning shots.  I just love the feeling of using a rangefinder!  I am not kidding about the feeling of going home to momma!  They take me back to my early days of photography when a rangefinder was all that I had and used.  They were and still are a nitch camera system.  You generally will not find someone out shooting birds in flight images with one, but that is OK  with me because after 50 years of shooting, I am soooo TIRED OF BIRDS (well except for hummingbirds but I can do those just fine with a rangefinder).

Outer Banks Fishing Pier, 250 second Exposure Leica M Monochrom

Outer Banks Fishing Pier, 250 second Exposure Leica M Monochrom

So what makes me smile about the M Monochrom?  The ease of use, the CRISP release of the shutter, the incredible functionality of the camera and its wide dynamic range!  I love the way it feels in my hands and responds to my control!  I even love the sound of it. It is almost sensual in nature!  Now, couple that with the amazing images that a pure B&W 18 mega pixel sensor with NO Brayer filter and no anti-aliasing filter can create you will be left breathless with the results.

So for this simple and short post about achieving emotional nirvana, I will keep it to just 2 images that make me feel good. Now that I am creatively re-inspired I can go out again with my color camera (rangefinder of course) and while looking at my scenes in B&W create color images again!

Thank you for stopping by for a visit to the blog…

Mar 14 2015

Creating Digital Negatives For Van Dyke Brown Printing


How I make my Image Stack for Digital Negatives…

Green Negative for UV blocking.

Green Negative for UV blocking.

Easy Digital Negatives is another remarkable book by Peter Mrhar

Easy Digital Negatives is another remarkable book by Peter Mrhar

This post is about how I create my Digital Negatives for printing in Van Dyke Brown.  Before I get into the meat of the subject I need to tell you that I am a follower of Peter Mrhar’s gradient maps for creating my negatives rather than using curves.  The maps will allow you to create a much more controlled negative without the issues normally seen in curves like wild spikes and twists which can really mess up your image.  Peter has written a book on the subject called Easy Digital Negatives which can be purchased on Amazon for a small fee.  The entire book leads up to the last chapter where he gives you an automated script that plugs into Photoshop that will create the gradient map.   Read the entire book first to understand how to develop a exposure test strip and a 245 step print that his script need in order to build the map.

The basic recipe that Peter gives is:

  1. Create a exposure test strip to get the correct exposure under your UV lights for perfectly exposed dark tones (black/Brown).  You do this with a piece of sensitized paper with a strip of un printed negative material covering 1/2 of the paper.  You then place a total UV blocking material leaving 1 inch of uncovered space, and expose for 1 min.  Then move the UV blocking material to uncover another inch of open paper/film for another min.  Repeat this procedure for about 10 min to create your test chart.   Annotate each exposure with pencil on the paper prior to developing to know what the exposure time was for each movement of the blocking material.  Process and completely dry.  Where the darkest tone that was under the unprinted negative material matches the darkest tone next to it on the paper only side you get your max exposure time.  This then becomes your base exposure for the paper/emulsion comes from.  You will need to do any paper treatments to your paper first like acid washing or applying Fumed Alumina.
  2. Van Dyke Brown Step Wedge Calibration Chart for 3 Min Exposure

    Van Dyke Brown Step Wedge Calibration Chart for 3 Min Exposure

    Now print your 256 step chart that Peter provides on a piece of paper treated the same as in step 1, with a UV blocking color which you will learn about below.  Process and dry.  Scan the resulting image according to Peter’s instructions and feed it to his script in Photoshop and it will pop out a Gradient Map for you to place in your image stack (example below).

That is all there is to it to create your gradient map (his script will also create a curve if you so desire).

Ok, lets talk about how you put together your file to create your digital negative once your have your gradient map in hand! Below is a copy of my adjustment layers in my digital negative file.

Image Stack in Photoshop for Digital Negative

Image Stack in Photoshop for Digital Negative

Starting at the bottom and working up, take a look at each layer:

  1. Background, default layer in every PS file.
  2. White Background, if you select this the non image area of your negative will print black (green) and leave the emulsion unexposed and white.
  3. Transparent Background, basically the same as layer 2.  I have this here so that I can select it and be able to read my text layer above on the negative.
  4. Black Background, if you select this layer then you will get a negative with the non image area printing white which will force expose the paper black.
  5. 256 step tablet.  You can select this layer to print a test chart.
  6. Picture Goes Here.  Place your image to be printed above this layer.
  7. Picture, REMEMBER even though we are printing a B&W image it MUST be in RGB mode because we are going to print the negative in COLOR to have a UV blocking layer on the top of the stack!
  8. Text layer  with data to be printed on the paper but separated from the image.  This is the bottom of a grouped set of layers that are all selected by simply selecting the group name, read on…
  9. Gradient Map for Lana Paper, acid washed and exposed for 2.5 min.  This is the meat of the layer stack.  This one layer will correct your MID TONES while the 2.5min exposure will correct for the dark tones.  This layer is what make your negative work.
  10. Lana paper group name.  Select this and the next 2 will automatically be selected. I have expanded them so that you can see them here for explanation.
  11. Group of 3 layers for Stonehenge papers with the same basic steps as 8, 9 & 10 with the only difference being a GRADIENT MAP created for Stonehenge paper rather than Lana paper!  you can have groups for each of your papers used in the stack and simply check the boxes you need for the paper you are going to print on!
  12. Invert, you MUST click on this prior to printing the create your negative image, switching your blacks & whites.
  13. Red UV blocking color, click to choose, be careful to not select both Red and Green.
  14. Green UV blocking color, click to choose, be careful not to select both Green and Red.

RULES:

  • Select ONE and ONLY ONE gradient map group or your picture will not print properly!!
  • Select ONE and ONLY ONE color UV blocking color or you picture will not print properly!!

Let’s talk a little about the UV blocking colors.  It seem a little strange to use a COLOR layer when printing B&W but you need to realize that some colors are better than B&W for controlling your UV exposures!  I have 2 color layers included in my image stack but there can be many others depending upon your printer, ink set and choice in negative film.  For my system (Epson 7900 24 inch printer using the Image Print V9 RIP) I have found that the Green layer works much better.  I am going to show you the difference below between using a B&W negative vs. the GREEN negative.  Pay close attention to the density of the grasses next to the sky in both prints.

First using a B&W negative with the same gradient map…

B&W negative

B&W negative

As you can see the density of the negative especially in the grasses looks great, but when you look at the output print you can see that the grasses all turn white at the horizon and get lost!

Bent Tree, B&W Negative

Bent Tree, B&W Negative

Now let’s take a look at the negative with the GREEN UV blocking layer…

Green Negative for UV blocking.

Green Negative for UV blocking.

The first thing that you should notice is that the density of both the sky and the grass seems much less dense but when you look at the output print the difference is amazing!

Bent Tree, VDB, w/ green negative

Bent Tree, VDB, w/ green negative

The grasses are now full of texture and you do not loose any detail at the horizon.  The exposure on both images are the same thus you have the same amount of dark areas of shade and in the tree, but the mid tones now are full of greater details.  This was simply achieved by adding the color UV blocking layer.

As I talk about these technical details they may seem simple, but it did take a while for me to master them in all of their glory.  The image used as an example for you is not yet to my liking.  The sky is a little too dark and the shadows are too black.  I have just this week created a new negative with corrections for those specific areas and will be printing this image again tomorrow!

Nothing comes easy with alternative printing. Our printing lives are full of trial and error, but once we master the basics of the digital negative the trial and error period will drop down considerably.

You can download a copy of my PSD negative stack files both here in my download link on the bottom of the right hand menu and on Facebook in the Van Dyke Brown Printing group or in the Digital Negatives for Contact Printing group.  There is a download file button on the top of each group page that will take you to these files.

I hope that this has been helpful for you. If you have any questions on this process please leave a comment here or join the FB groups above and you will find a great group of people on each group who can and will assist you in your process!

Mar 9 2015

Using Fumed Alumina To Fix Paper Issues in Van Dyke Brown


An Easy & Cost Effective Way To Fix Paper Issues!

Stormy Seas, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned

Stormy Seas, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned, 720nm Infrared

Testing Fumed Alumina…

Van Dyke Brown emulsion is basically on the acidic side of things chemically and as a result of this I have been forced to wash most of my papers with a acid bath. This caused a increase in my process by 2 days. So I am testing Fumed Alumina which is acidic unlike Fumed Silica which is neutral. I decided to go with the Alumina test first and will do a followup post down the line with the Fumed Silica.

Bent Tree, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned

Bent Tree, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned, IR400 120 Film

Initial results were quite pleasing with both Revere Platinum and Lana Aquarelle papers. I got a MAJOR increase in Dmax with both the Lana and Revere papers, but upon completion of my final wash the Revere was VERY EASY to damage with finger smudges until it dried. The Revere had a tendency for the Alumina to easily rub off the Alumina while wet whereas the Lana was strongly attached.

Anderson Mill, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned

Anderson Mill, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned, Leica M Monochrom

The Alumina did fix ALL of the spotting issues that I had when using the Revere Platinum paper but the fact that it will rub off when wet causes some concern but it is easily overcome with careful handling.

Magnolia, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned

Magnolia, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned

The Process:

  1. Dry roll on the Fumed Alumina in 2 directions and rap the paper edge on the table to remove the excess.  Make sure that you use a good mask to filter out this dust as it might irritate your lungs.  DO NOT OVER COAT or you will get streaks when you coat the emulsion.  The rolling step only takes about 30 seconds! You will need to put about 1 TSP of the Alumina into a small paint tray then pre load a small (3″) HARD foam roller with it.
  2. Coat as normal after you roll on the Alumina. You will need about 12 extra drops of VDB emulsion due to it absorbing more. My basic quantity of VDB emulsion for a 8×12 sheet of paper coated with Alumina is 48 Drops of emulsion and 2 drops of Tween 20 at 25% (you will need to dilute the Tween from 50%) solution.  For this post I brushed on the emulsion.  In the past I would normally use a glass rod for coating but the Alumina creates a very rough surface and I was afraid of damaging the paper.
  3. Dry and Expose. Here you will find that the addition of the Alumina will DECREASE your exposure about 1.5 stops!
  4. 1st water bath with distilled water and a pinch of citric acid, 2 min.  This bath will remove any extra ferric ammonium citrate which will cause a yellow paper stain. This bath will darken the print.  Do not worry as the FIX will balance contrasts and bring out the highlights!
  5. Fresh water bath to remove citric acid. 2 min. If you are Gold Toning, this step is VERY important as any Citric Acid will destroy the toner bath!
  6.  Gold toning bath 2 to 5 min to taste.  The toning process requires CONSTANT AGITATION! After 2 or 3 prints toned add 5ml/print of Gold Chloride to bring the bath back up to strength. This  toning bath will further darken the print.  Do not worry as the FIX will balance contrasts and bring out the highlights!
  7. Fix for 2 min with Sodium Thiosulfate for 2 min. 30g/L. I do not believe that any further time will help the process.
  8. Final moving fresh water bath for 30 min.
  9. Air dry,  I spread out old towels on a table top and place the print on it for about 10 min to absorb most of the water thru the back of the print.  I will then hang the prints to dry by a corner.
  10. Use a  heat press to flatten your prints at 170deg for 20 seconds. The heat press step is to make the paper flat again.
  11. Hand rub in SOFT custom wax coating for protection then heat to force the wax to be absorbed into the paper fiber with a hair drier (more about this in a future post).
Dinghy, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned

Dinghy, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned, Leica M Monochrom

All in all this was a VERY easy fix to the acid washing step  and only added about 30 seconds to roll on the Alumina. The Fumed Alumina can be purchased at Bostick & Sullivan for $15/500g which will do about 100 sheets of 8×12 paper.

2 Dinghys, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned

2 Dinghys, Van Dyke Brown, Lana Paper, Fumed Alumina Brush Coated, Gold Toned, Leica M Monochrom

The increase in Dmax with the Fumed Alumina is amazing and the resulting images are stunning.

Please let me know what you think of this post and with suggestions for future posts!

Jan 25 2015

Continued Work In Van Dyke Brown Alternative Print Process!


Perfection in Brown…



Glade Creek Mill, Van Dyke Brown, Revere Platinum Paper exposed for 5 Min

Glade Creek Mill, Van Dyke Brown, Revere Platinum Paper exposed for 5 Min



Oak Reflections in Infrared, Van Dyke Brown, Revere Platinum Paper, 3 Min Exposure

Oak Reflections in Infrared, Van Dyke Brown, Revere Platinum Paper, 3 Min Exposure

After another 2 weeks working on the negative density, I have finally gotten to the point of good negatives, not great yet but I will get there.  I have to master the use of UV blocking color in the negative for them to be perfect and that is a project for the future. To date though I have reached perfection using normal B&W negatives.

My CORRECTED Digital Negative for the Van Dyke Process

My CORRECTED Digital Negative for the Van Dyke Process

Here is the corrected negative that I used in the image of the Oak trees above.  It is much dense and has been corrected for the mid tones as printed in the Van Dyke Brown Process!  It has much greater contrast and required only a 3 min exposure in my UV unit.

One thing that you have to remember when making your UV exposures is to place the ink side of your negative down on the paper surface.  If you reverse this the picture will be backwards, but more importantly, the UV light will burn the ink surface and ruin both the negative and the print.

B&W Negative for Van Dyke Brown Print exposure calculated for 3 Min.

B&W Negative for Van Dyke Brown Print exposure calculated for 3 Min.

Compare it to the negative on the right.  This negative was used in the previous post here where the image printed much darker and with less mid tone data.  Take a close look at the difference between the two negatives, the first has much brighter areas for increased black contrast and more detail in the trees. The difference is amazing and was easily achieved by the process discussed below…

Here is a small copy of the print generated by the 2nd negative from the previous post.  Notice how much darker it is and that there is no detail in the mid tones of the image!  It only took me a short while to create the Gradient Map from the process that I learned in Peter Mrhar’s book below.

Van Dyke Brown Print, Over Exposed by 2 stops due to the uncorrected negative

Van Dyke Brown Print, Over Exposed by 2 stops due to the uncorrected negative

Easy Digital Negatives is another remarkable book by Peter Mrhar

Easy Digital Negatives is another remarkable book by Peter Mrhar

Easy Digital Negatives is another remarkable book by Peter Mrhar that I use in the creation of my negatives.  It enables you to easily create Gradient Maps to adjust the mid tone values of your negative tailored to the alternative process that you are printing with!  I highly recommend this text over all of the others!

There are several good books on Digital Negatives out there but As I said the is the easiest that I have read and used plus the results of using a Gradient Map over a Custom Curve.  I suggest that you purchase several texts and try them in your workflow to see what works best for you!

I hope that you enjoyed this short post on the Van Dyke Brown Process.  You can look for more about it in the future!

Jan 19 2015

One Image, One Paragraph…


My favorite image from my visit to Georgetown today…

Stormy Seas… Calm Dock…

Stormy Seas... Calm Dock...

Stormy Seas… Calm Dock…

I had to sit in the Georgetown gallery today. On my way there I stopped at Stormy Seas, my favorite shrimp boat in the area.  I had the Leica M Monochrom with me and the Tri-Elmar 16-18-21 mm lens on it as well as the FRANKEN-VIEWER which enables me to compose the image with ultra-wide lenses on the Monochrom. Did I mention that the Leica M Monochrome is a B&W ONLY camera system? The sky had this amazing gradient across it going from dark gray to bright silvery light on the horizon and the water that you could slide across… Oh My, the water was so perfectly smooth and mirror-like that I stood there stunned with camera in hand just hypnotized at the magic and taking it all in.  But alas, I only had a minute to spare so I took 3 differently composed images at -1ev, f/11 and 1/1500s.  This is the result: a simple, well balanced image, so full of tonality that it is dripping from the bottom all over my feet….

Enjoy while I clean my shoes…

Jan 19 2015

Van Dyke Brown Printing, 1842


A new (read OLD) way of printing!

8x12" Van Dyke Brown Print

8×12″ Van Dyke Brown Print

Alternative Printing from History!

Van Dyke Brown is an early photographic printing process. The process was so named due to the similarity of the print color to that of a brown oil paint named for Flemish painter Anthony van Dyck.

The Vandyke brown print is based on the first iron-silver process, the argentotype, invented in 1842 by the English astronomer, Sir John Herschel. Both processes utilize the action of light on ferric salts and their chemistry is very similar. The Vandyke process gets its name from its similarity in color to the deep brown pigment used by the Flemish painter Van Dyck. Vandyke brown prints are very simple and economical to make, with the sensitizer consisting of three readily available chemicals. Clearing is carried out in water and fixing is done in a weak solution of hypo.

Van Dyke Brown Step Wedge Calibration Chart for 3 Min Exposure

Van Dyke Brown Step Wedge Calibration Chart for 3 Min Exposure

As you can see, this is a very early way of printing developed a long time before our current Silver Salt paper process.  The images are a deep brown instead of the normal black and white that we are used to seeing.  They are somewhat easy to create provided that you have done your homework and created the proper calibration images to create a calibration Gradient Map or Curve to apply to your negatives which adjust them for loss of mid tones in the printing process.

This is strictly a CONTACT PRINTING technique that requires a true negative that is placed on top of paper that YOU as the artist coat yourself with the Van Dyke Brown emulsion that you mix from simple chemistry!   The coating process is done with a special brush that requires a very light touch or a glass coating rod that you use to push a line of liquid emulsion across the paper.

B&W Negative for Van Dyke Brown Print exposure calculated for 3 Min.

B&W Negative for Van Dyke Brown Print exposure calculated for 3 Min with the calibration applied.

The liquid emulsion is measured by the number of drops from a glass eye dropper into a small glass then with a drop of two of a wetting agent like Tween 20 to help the coating process.  The paper/emulsion is allowed to dry then the negative which was created using my Epson 7900 printing on transparency material is placed on top of the coated paper.  This sandwich is then placed in a printing box filled with 12 Fluorescent Black Light tubes which then expose the paper with UV light.  The exposure for the current paper I am using (Revere Platinum) has been calibrated to 3 or 4 min based upon the test chart above.

Van Dyke Brown Print, Over Exposed by 2 stops.

Van Dyke Brown Print, Over Exposed by 1.5 stops.

This process is a POP process in which the image after being exposed can be seen on the paper once removed from the UV box.  It is orange and yellow in color.  It is placed in 2 consecutive distilled water baths that remove the yellow and darken the orange.  Then it is placed in the fixer solution (Sodium thiosulfate) for 2 min.  When the image is placed in the fix, it IMMEDIATELY changes from orange to a very dark brown and white picture. Finally the print is placed in a live water wash for 30 min then dried!

This is a simple process that creates beautiful images that will leave you breathless as you view them!  I am going to further develop and learn the process over the next month or two before I start on mastering the Platinum/Palladium printing process as well!

Look forward to many more posts on the processes as I master them!
